RD 22S
Hydraulic Drifter
- Impact Output Power: 22kW
- Drilling Diameter: Ø89-127mm
The RD 22S hydraulic drifter features a two-stage damping system and a dual-circuit hydraulic design. With a robust 22kW output power, this hydraulic drifter is specifically engineered for demanding applications in underground and open-pit mining, tunneling, water conservancy, national defense, and other projects requiring rock drilling.
The RD 22S hydraulic drifter is compatible with T45 (standard) and T51 shank adapters.
Request a Quote →
Product Parameters
| Max. Impact Power | 22kW |
| Impact Frequency | 38Hz |
| Max. Impact Pressure | 200bar |
| Impact Oil Flow | 120L/min |
| Max. Rotation Torque | 1522Nm |
| Max. Rotation Speed | 0-140rpm |
| Max. Rotation Pressure | 140bar |
| Rotation Oil Flow | 75L/min |
| Drilling Diameter Range | 89-127mm |
| Compatible Shank Adapters | T45/T51 |
| Operating Weight | 230kg |
Accessories
Drill string flushing
Diaphragm
Spline copper sleeve
Shank adapter
Shank bushing
Eaton hydraulic motor
